PIT FLOOR JACK 1.5T
SKU
OH 0289
Product values
View all features
Ideal for working on transmissions, gearboxes, etc. in the pit floor, in complete safety and with minimum effort.
6,990 €
VAT Excl.
Characteristics
| Item name | PIT FLOOR JACK 1.5T |
|---|---|
| Bar code | 3701555311692 |
| Introduction | Ideal for working on transmissions, gearboxes, etc. in the pit floor, in complete safety and with minimum effort. |
| Text | Thanks to its double-piston cylinder (high height) and wheel-mounted chassis, you'll be able to work on any HGV or other vehicle, and in any pit. The table can be swivelled sideways, from left to right, and tilted forwards and backwards, enabling you to couple a gearbox, for example, to its engine flywheel with great precision and effortlessness. For safety, you can secure the operation with the locking chain. What's more, the manual electro-hydraulic motorization provides a powerful 1.5T up/down stroke for precise coupling of components. |
| Product highlight | Working comfort |
| Specifications |
Specifications : - capacity: 1500kg - first piston Ø: 50mm - second piston Ø: 80mm - length: 850mm - width: 450mm - max height: 2300mm - minimum height: 1250mm - baseplate dimensions : - length: 1040mm - width: 800mm - 2 Ø 200mm braked wheels - 2 swivel wheels Ø 200mm - weight: 200kg |
| Warranty period | 2 years |
| Vehicle type | HGV |
| Product weight (kg) | 200 kg |
| Max. height | 230 mm |
| Min. height | 125 mm |
| Maximum load (Kg) | 1,500 kg |
| Tariff code | Tariff Equipment (TE) |
| Warranty Procedure | DIAGNOSTIC |
