New
Double scissors post lift 3.5T 240V to be installed or flush-mounted
SKU
PE 6400M
Product values
View all features
Particularly suited to paint, body repair and quick service activities.
Choice of installation: free-standing or built-in.
Easy access: low 105mm ground clearance, lockable ramps to extend platforms.
Maximum comfort and safety: double hydraulic master-slave safety system.
4,699 €
VAT Excl.
€75
Characteristics
| Item name | Double scissors post lift 3.5T 240V to be installed or flush-mounted |
|---|---|
| Bar code | 3701555326641 |
| Text |
Particularly suited to paint, body repair and quick service activities. Choice of installation: free-standing or built-in. Easy access: low 105mm ground clearance, lockable ramps to extend platforms. Maximum comfort and safety: double hydraulic master-slave safety system. |
| Product highlight | Can be used free-standing or built-in |
| Specifications |
Specifications : - lifting height: 105-1990mm - track width/length: 650/1547-2077mm - system synchronization: photo cell - control panel - drive power: 2.2kw - Aluminum engine - drive voltage: (1 ~ + N) 240V/50/Hz - emergency lowering system in case of power failure - intermediate stop at 20 cm from the ground for user safety and anti-crushing audible signal -supplied with 4 x 35 mm buffers |
| Advice |
Please consult us for installation and commissioning. Under warranty, installation and commissioning must be carried out by a professional. Transport costs not included. |
| Warranty period | 2 years |
| Power | 2200W |
| Voltage | 240V |
| Length (mm) | 2,077 mm |
| Width | 1,990 mm |
| Height | 1,900 mm |
| Maximum load (T) | 3.50 T |
| Tariff code | Tariff Equipment (TE) |
| Composition of nomenclature |
1 x PE 6400M-1 - Double scissors post lift 3.5T 240V to be installed or recessed 1/2 1 x PE 6400M-2 - Double scissors post lift 3.5T 240V to be instal. or flush-mounted 2/2 3 x SA 3012 - Hv46 hydraulic oil 5l |
| Warranty Procedure | INTERVENTION |
| Customer benefit | Supplied with HV46 hydraulic oil and ground fixing kit |
| Pneumatic power supply required | YES |
| Circuit breaker/Cable section | 16A D / 3x2.5mm2 |
